The VRO Readout is compatible with all 5V incremental encoders. An encoder, mounted directly to the slider gives a true and accurate reading eliminating lead screw and backlash errors.

Modifications for use in a vacuum environmentĮncoders and VRO™ Encoder Readout (Manual or Motorized Series) – For a high resolution position readout an encoder and Velmex's VRO encoder readout can be mounted to most linear UniSlide assemblies.

Specialized coatings for specific applications such as food processing or medical applications.

Other coatings maybe available with a minimum lot charge:

Black Anodizing, additional colors also available.

Optional finishes are available at an additional charge and include: Readouts in either 0.01" or 0.1 mm.Īperture (Manual AXY25 only) – Square window through center for a variety of optical and alignment applications including microscope and laser positioning, inspection, etc.įinishes (Manual or Motorized Series) – Standard UniSlide Assemblies have a brushed aluminum finish.

X and y axis adjustment creation workshop series#

Revolution Counter (Manual Series Only) – A mechanical revolution counter provides a convenient 1/10 revolution increment count.

The lock is mounted on the slider/carriage on each axis. Slider Lock (-SL) (AXY25 only) – This lock is mounted at the mid-point on the base and is tightened to prevent slider movement. Thumbscrew-on-Lead-Screw Lock (-TL) (AXY40 and AXY60 only) – An easy method to affix the slider utilizing a simple thumbscrew on the lead screw at the end bearing block of each axis. Locks – (Manual Series only) - Are required on both axis. A Graduated Knob with the scale mounted on the top side of the base is available as an option on Series AXY40 and AXY60 Tables. Options/Accessories for UniSlide® XY TablesĪlternative Knobs (Manual Series only) – The knob with a crank is standard on Velmex XY Tables Series AXY40 and AXY60.

X and y axis adjustment creation workshop manual#

Information on stage composition, tolerances, wear and design for specialty applications.īasic Dimensions for Manual UniSlide XY Tables

X and y axis adjustment creation workshop code#

Screw Motion Type Code Letter – Standard AccuracyĠ.003"(0.076 mm) over entire travel distance. Please contact Velmex Application Engineers to configure a system that will meet your exact requirements. effect the actual capability of any assembly. Available in a variety of lead screw pitches.įactors such as size of the motor, size of the payload, travel distance, mounting direction/plane, etc. These models feature a large, unobstructed work surface. MAXY60 Series – Three high profile models with a travel range of up to 9" by 9" (22.9 cm x 22.9 cm). Available in a variety of lead screw pitches. MAXY40 Series – Two medium profile models with a travel range of up to 5" by 5" (12.7 cm x 12.7 cm). Motorized XY Tables - Model / Series Options

Other finer and coarser screws are available. Standard lead screw advance is 0.100"/revolution. These models feature a large, unobstructed work platform. Other finer and coarser screws are available.ĪXY60 Series – Three high profile models with a travel range of up to 9" by 9" (22.9 cm x 22.9 cm). Standard lead screw advance is 0.100"/revolution.ĪXY40 Series – Two models with a travel range of up to 5" by 5" (12.7 cm x 12.7 cm). The models in this series can be purchased with or without a center window / aperture. These models feature an unobstructed work platform. Manual XY Tables - Model / Series OptionsĪXY25 Series – Three low profile models with a travel range of up to 4" by 4" (10.2 cm x 10.2 cm).
